Slitting line
The Hong Ky slitting line 0.5~3.2x1350 is designed for efficiently uncoiling wide steel coils into smaller sizes as per the required specifications. Perfect for industries such as steel pipe production, home appliances, automotive parts, and more. Made in Vietnam.
- High-speed decoiler for precision uncoiling of steel coils
- Suitable for processing galvanized coils, hot-rolled, cold-rolled, and stainless steel coils
- Features dual cutting tool units for quick blade changes
- Fully automated system with PLC control and HMI touchscreen for ease of operation
- Enhanced safety with sensor systems and protective barriers
Overview
Product overview:
The Hong Ky slitting line (model 0.5~3.2x1350) is engineered for efficient coil uncoiling, designed to handle a variety of materials with precision. Manufactured in Vietnam, it provides a comprehensive solution for steel machinery applications, featuring both robust performance and user-friendly automation.
Features:
- Dual cutting tool units for fast blade replacement
- Hydraulic system and concealed wiring ensure a clean and efficient work environment
- Advanced PLC and HMI touchscreen system for intuitive operation
- Built-in SCADA software for monitoring machine data and maintenance alerts
- High-speed uncoiling with minimal downtime, ensuring optimized productivity
Applications:
This uncoiler machine is ideal for industries like:
- Steel pipe production
- Home appliances
- Automotive parts manufacturing
- Metalworking and construction
Suitable materials:
- Galvanized steel coils
- Cold-rolled steel coils
- Hot-rolled steel coils
- Stainless steel coils
Contact information:
Contact us at +84 909 073 505 for export inquiries.
Technical Specifications
| Specification | Unit | Value |
| Model | - | 0.5~3.2 x 1350 |
| Material Type | - | SS400, GI, HR, CR |
| Material Thickness | mm | 0.5~3.2 |
| Steel Coil Width | mm | Max 1350 |
| Steel Coil Weight | Ton | Max 20 |
| Minimum Slit Width | mm | Min 30 |
| Maximum Feeding Speed | m/min | Max 160 |
